Switch housing
- Metal
Interface
- MG-105:Five RJ-45 100/1000/2500 Mbps Ethernet ports with auto MDI/MDIX support
- MG-108:Eight RJ-45 100/1000/2500 Mbps Ethernet ports with auto MDI/MDIX support
LED Indicator
- PWR: Power
- Per port: Link/Activity
- Amber: 100/1000 Mbps
- Green: 2.5 Gbps
- Power Supply
- AC-to-DC external power adapter
- Input: 100-240 V AC, 50/60 Hz
- Power Consumption
- MG-105 (max./min.): 9.34 watt / 3.83 watt
- MG-108 (max./min.): 12.24 watt / 4.48 wat
- Standard
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE802.3ab 1000BASE-T
- IEEE 802.3bz 2.5GBASE-T
- IEEE 802.3x full duplex operation and flow control
- IEEE 802.1p QoS
- IEEE 802.3 Nway auto-negotiation
Performance
- Switching capacity:
- MG-105: 25 Gbps
- MG-108: 40 Gbps
- Switching forwarding rate:
- MG-105: 18.6 Mpps
- MG-108: 29.8 Mpps
- MAC address table: 16 K
- Packet buffer: 12Mb
- Jumbo frame supports up to 12 KB
Features
- 100M, 1G and 2.5G ports for multi speed
- Fanless and quiet
- Plug and Play, Easy use and Quick Install
- Desktop and Wall mount
- Auto-MDI/MDIX in all ports
Item dimensions (WxDxH):
- MG-105: 160 x 110 x 26 mm(6.3" x 4.33" x 1.02")
- MG-108: 240 x 106 x 26 mm(9.45" x 4.13" x 1.02")
Item weight:
- MG-105: 460g (1.01 lb.)
- MG-108: 640g (1.41 lb.)
Packing dimensions (WxDxH):
- MG-105: 215 x 133 x 79 mm (8.46" x 5.24" x 3.11")
- MG-108: 256 x 132 x 78 mm (10.08" x 5.2" x 3.07")
Packing weight:
- MG-105: 919.6g (2.03 lb.)
- MG-108: 1,122g (2.47 lb.)
Operating Environment
- Temperature: 0°C to 40°C (32°F to 104°F)
- Humidity: 10% to 90% (Non-condensing)
Storage Environment
- Temperature: -40°C to 70°C (-40°F to 158°F)
- Humidity: 5% to 95% (Non-condensing)
| Veri Transfer Hızı | : | 1Gbps |
| Port Sayısı | : | 5 Adet |
| PoE Desteği | : | Yok |
| SFP Yuva | : | Yok |
| Rack Kasa | : | Uyumlu Değil |
| Yönetim | : | Yönetilemez |
